FishFace

14 dpf Development

[ Back to The ceratohyal: associated bones and articulations]
Info Image

Please hold mouse over images to see annotations.

14 dpf
zc81Tg
Alizarin red
Ventral
Lateral
Description

By 342 hpf, the ceratohyal (ch) has grown considerably from that seen at 249 hpf, with a dramatic increase in dorsal-ventral size at the posterior end. Articulations of the ceratohyal with the interhyal (ih), the contralateral ceratohyal, and branchiostegal rays 1, 2, and 3 (bsr1, bsr2, bsr3) are visible. The ventral hypohyal (hhv) bone has now spread posteriorly in the perichondrium across a deep cleft that has formed at the ventro-anterior tip of the ceratohyal. Also visible is the epihyal (eh) bone in the dorso-posterior aspect of the ceratohyal perichondrium, which in lateral view’ is covered by the interopercle (iop).
