FishFace

14 hpf Development

[ Back to Pharyngeal development: Pre-skeletal]

Info Image
Please hold mouse over images to see annotations.
14 hpf
zc81Tg
Alizarin red
Ventral
Lateral
Description

By 340 hpf, developing elements of the pharyngeal skeleton have grown dramatically, compared to 247 hpf. Elements shown here include Meckel’s (Mk), palatoquadrate (pq), basihyal (bh), ceratohyal (ch), interhyal (ih), and hyosymplectic (hs) cartilages, and premaxilla (pm), maxilla (mx), dentary (d), anguloarticular (aa), retroarticular (ra), quadrate (q), ventral hypohyal (hhv), ceratohyal bone (chb), branchiostegal rays 1-3 (bsr1, 2, 3), symplectic (sy), hyomandibula (hm), preopercle (pop), interopercle (iop), subopercle (sop), opercle (op), urohyal (uh), and ceratobranchial 5 (cb5) bones. Also visible are the scleral (sc) cartilage of the eye and the cleithrum (cl) bone of the pectoral fin skeleton.
